org.xlightweb.client
Class HttpClientConnection

java.lang.Object
  org.xlightweb.AbstractHttpConnection
      org.xlightweb.client.HttpClientConnection

All Implemented Interfaces:

Closeable, IHttpClientEndpoint, IHttpConnection, IConnection, IDestroyable

public final class HttpClientConnection
extends org.xlightweb.AbstractHttpConnection
implements IHttpClientEndpoint

Represents the client side endpoint implementation of a http connection. The HttpClientConnection supports constructors which accepts the remote address or a existing INonBlockingConnection. A INonBlockingConnection can become a HttpClientConnection at any time.

Nested Class Summary

Nested classes/interfaces inherited from class org.xlightweb.AbstractHttpConnection

org.xlightweb.AbstractHttpConnection.AbstractExchange, org.xlightweb.AbstractHttpConnection.IMessageHandler, org.xlightweb.AbstractHttpConnection.IMessageHeaderHandler, org.xlightweb.AbstractHttpConnection.IMultimodeExecutor, org.xlightweb.AbstractHttpConnection.RequestHandlerAdapter, org.xlightweb.AbstractHttpConnection.ResponseHandlerAdapter

Nested classes/interfaces inherited from interface org.xsocket.connection.IConnection

IConnection.FlushMode

Field Summary

Fields inherited from interface org.xlightweb.client.IHttpClientEndpoint

DEFAULT_AUTOHANDLE_100CONTINUE_RESPONSE

Fields inherited from interface org.xlightweb.IHttpConnection

DEFAULT_CONNECT_TIMEOUT_MILLIS, DEFAULT_DATA_RESPONSE_TIMEOUT_MILLIS, DEFAULT_RESPONSE_TIMEOUT_MILLIS

Fields inherited from interface org.xsocket.connection.IConnection

DEFAULT_AUTOFLUSH, DEFAULT_CONNECTION_TIMEOUT_MILLIS, DEFAULT_FLUSH_MODE, DEFAULT_IDLE_TIMEOUT_MILLIS, INITIAL_DEFAULT_ENCODING, MAX_TIMEOUT_MILLIS, SO_KEEPALIVE, SO_LINGER, SO_RCVBUF, SO_REUSEADDR, SO_SNDBUF, SO_TIMEOUT, TCP_NODELAY

Constructor Summary

HttpClientConnection(InetSocketAddress address)
constructor

HttpClientConnection(InetSocketAddress address, Executor workerpool)
constructor

HttpClientConnection(INonBlockingConnection connection)
constructor

HttpClientConnection(String host, int port)
constructor

HttpClientConnection(String host, int port, Executor workerpool)
constructor

HttpClientConnection(String host, int port, Executor workerpool, IHttpConnectionHandler connectionHandler)
constructor

HttpClientConnection(String host, int port, IHttpConnectionHandler connectionHandler)
constructor

Method Summary

protected static void	addConnectionAttribute(IHttpResponseHeader header, IHttpConnection con)
protected static int	availableSilence(NonBlockingBodyDataSource dataSource)
IHttpResponse	call(IHttpRequest request) performs a request.
void	close()
protected static void	forward(NonBlockingBodyDataSource dataSource, BodyDataSink dataSink)
protected static String	generateErrorMessageHtml(int errorCode, String msg, String id) generates a error page
protected static IBodyDataHandler	getDataHandlerSilence(NonBlockingBodyDataSource dataSource)
protected static int	getDataReceived(NonBlockingBodyDataSource dataSource)
protected static NonBlockingBodyDataSource	getDataSourceOfInMemoryBodyDataSink(BodyDataSink dataSink)
protected org.xlightweb.AbstractHttpConnection.IMessageHeaderHandler	getMessageHeaderHandler()
protected static IHeader	getReceivedHeader(ProtocolException pe)
long	getResponseTimeoutMillis() returns the response timeout
protected static boolean	isComplete(NonBlockingBodyDataSource body)
protected static boolean	isNetworkendpoint(NonBlockingBodyDataSource dataSource)
boolean	isServerSide()
protected static boolean	isSupports100Contine(IHttpResponseHandler handler)
protected static BodyDataSink	newInMemoryBodyDataSink(String id, IHttpMessageHeader header)
protected void	onConnectionTimeout()
protected void	onDisconnect()
protected void	onIdleTimeout()
protected void	onMessageCompleteReceived(IHttpMessageHeader header)
protected static ByteBuffer[]	readByteBufferByLengthSilence(NonBlockingBodyDataSource dataSource, int length)
protected void	removeMessageHandler(org.xlightweb.AbstractHttpConnection.IMessageHeaderHandler messageHandler)
protected static void	schedule(TimerTask task, long delay, long period) schedules a timer task
IFutureResponse	send(IHttpRequest request) send the request.
BodyDataSink	send(IHttpRequestHeader requestHeader, IHttpResponseHandler responseHandler) send the request.
BodyDataSink	send(IHttpRequestHeader requestHeader, int contentLength, IHttpResponseHandler responseHandler) send the request in a plain body mode Connection-LifeCycle support: If the request header contains a 'Connection: close' entry, the connection will be closed after the HTTP transaction
void	send(IHttpRequest request, IHttpResponseHandler responseHandler) send the request.
protected static void	setDataHandlerSilence(NonBlockingBodyDataSource dataSource, IBodyDataHandler dataHandler)
void	setResponseBodyDefaultEncoding(String defaultEncoding) set the response body default encoding.
void	setResponseTimeoutMillis(long responseTimeoutMillis) set the response time out by performing the call or send method.
String	toString()

Methods inherited from class org.xlightweb.AbstractHttpConnection

activateSecuredMode, addConnectionHandler, closeQuitly, destroy, destroy, destroy, destroy, forwardBody, getAttachment, getBodyDataReceiveTimeoutMillis, getConnectionTimeoutMillis, getCountMessagesReceived, getCountMessagesSent, getCountReceivedBytes, getExecutor, getId, getIdleTimeoutMillis, getLastTimeDataReceivedMillis, getLastTimeHeaderReceivedMillis, getLastTimeMessageTailReceivedMillis, getLastTimeWritten, getLocalAddress, getLocalPort, getMaxWriteBufferSize, getNumOpenTransactions, getOption, getOptions, getReceviedHeader, getRemainingMillisToConnectionTimeout, getRemainingMillisToIdleTimeout, getRemoteAddress, getRemotePort, getSizeDataReceived, getSizeWritten, getUnderlyingTcpConnection, getWorkerpool, incCountMessageReceived, incCountMessageSent, init, isAcceptingChunkedResponseBody, isAutoUncompress, isContentTypeSupportsCharset, isEmpty, isForwardable, isOpen, isPersistent, isReceivingSuspended, isReuseable, isSecure, newDetailedClosedChannelException, newDoNothingResponseHandler, newEmtpyBodyDataSink, newFormEncodedRequestWrapper, newMultimodeExecutor, onConnect, onMessageWritten, onProtocolException, parseEncoding, removeConnectionHandler, resumeReceiving, schedule, setAttachment, setAutocompressThreshold, setAutoUncompress, setBodyCloseListener, setBodyDataReceiveTimeoutMillis, setBodyDefaultEncoding, setConnectionTimeoutMillis, setIdleTimeoutMillis, setLastTimeDataReceivedMillis, setLastTimeHeaderReceivedMillis, setLastTimeMessageTailReceivedMillis, setNetworkBodyDataSinkIgnoreWriteError, setOption, setPersistent, setWorkerpool, setWriteTransferRate, suspendReceiving, writeMessage, writeMessage, writeMessage, writeMessageSilence

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, wait, wait, wait

Methods inherited from interface org.xlightweb.client.IHttpClientEndpoint

getId

Constructor Detail

HttpClientConnection

public HttpClientConnection(String host,
                            int port)
                     throws IOException,
                            ConnectException

constructor

Parameters:

host - the remote host

port - the remote port

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

HttpClientConnection

public HttpClientConnection(String host,
                            int port,
                            Executor workerpool)
                     throws IOException,
                            ConnectException

constructor

Parameters:

host - the remote host

port - the remote port

workerpool - the workerpool to use

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

HttpClientConnection

public HttpClientConnection(InetSocketAddress address)
                     throws IOException,
                            ConnectException

constructor

Parameters:

address - the server address

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

HttpClientConnection

public HttpClientConnection(InetSocketAddress address,
                            Executor workerpool)
                     throws IOException,
                            ConnectException

constructor

Parameters:

address - the server address

workerpool - the workerpool to use

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

HttpClientConnection

public HttpClientConnection(INonBlockingConnection connection)
                     throws IOException

constructor

Parameters:

connection - the underlying tcp connection

Throws:

IOException - if an exception occurs

HttpClientConnection

public HttpClientConnection(String host,
                            int port,
                            IHttpConnectionHandler connectionHandler)
                     throws IOException,
                            ConnectException

constructor

Parameters:

host - the remote host

port - the remote port

connectionHandler - the connection handler

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

HttpClientConnection

public HttpClientConnection(String host,
                            int port,
                            Executor workerpool,
                            IHttpConnectionHandler connectionHandler)
                     throws IOException,
                            ConnectException

constructor

Parameters:

host - the remote host

port - the remote port

workerpool - the workerpool to use

connectionHandler - the connection handler

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

Method Detail

isComplete

protected static boolean isComplete(NonBlockingBodyDataSource body)

isNetworkendpoint

protected static boolean isNetworkendpoint(NonBlockingBodyDataSource dataSource)

addConnectionAttribute

protected static void addConnectionAttribute(IHttpResponseHeader header,
                                             IHttpConnection con)

isSupports100Contine

protected static boolean isSupports100Contine(IHttpResponseHandler handler)

forward

protected static void forward(NonBlockingBodyDataSource dataSource,
                              BodyDataSink dataSink)
                       throws IOException

Throws:

IOException

getDataReceived

protected static int getDataReceived(NonBlockingBodyDataSource dataSource)

newInMemoryBodyDataSink

protected static BodyDataSink newInMemoryBodyDataSink(String id,
                                                      IHttpMessageHeader header)
                                               throws IOException

Throws:

IOException

getReceivedHeader

protected static IHeader getReceivedHeader(ProtocolException pe)

getDataSourceOfInMemoryBodyDataSink

protected static NonBlockingBodyDataSource getDataSourceOfInMemoryBodyDataSink(BodyDataSink dataSink)

setDataHandlerSilence

protected static void setDataHandlerSilence(NonBlockingBodyDataSource dataSource,
                                            IBodyDataHandler dataHandler)

getDataHandlerSilence

protected static IBodyDataHandler getDataHandlerSilence(NonBlockingBodyDataSource dataSource)

availableSilence

protected static int availableSilence(NonBlockingBodyDataSource dataSource)
                               throws IOException

Throws:

IOException

readByteBufferByLengthSilence

protected static ByteBuffer[] readByteBufferByLengthSilence(NonBlockingBodyDataSource dataSource,
                                                            int length)
                                                     throws IOException

Throws:

IOException

close

public void close()
           throws IOException

Specified by:

close in interface Closeable

Overrides:

close in class org.xlightweb.AbstractHttpConnection

Throws:

IOException

onIdleTimeout

protected void onIdleTimeout()

Overrides:

onIdleTimeout in class org.xlightweb.AbstractHttpConnection

onConnectionTimeout

protected void onConnectionTimeout()

Overrides:

onConnectionTimeout in class org.xlightweb.AbstractHttpConnection

onDisconnect

protected void onDisconnect()

Overrides:

onDisconnect in class org.xlightweb.AbstractHttpConnection

generateErrorMessageHtml

protected static String generateErrorMessageHtml(int errorCode,
                                                 String msg,
                                                 String id)

generates a error page

Parameters:

errorCode - the error code

msg - the message

id - the connection id

Returns:

the error page

schedule

protected static void schedule(TimerTask task,
                               long delay,
                               long period)

schedules a timer task

Parameters:

task - the timer task

delay - the delay

period - the period

call

public IHttpResponse call(IHttpRequest request)
                   throws IOException,
                          ConnectException,
                          SocketTimeoutException

performs a request. This method blocks until the response (header) is received.

• Connection-LifeCycle support: If the request header contains a 'Connection: close' entry, the connection will be closed after the HTTP transaction

Specified by:

call in interface IHttpClientEndpoint

Parameters:

request - the request

Returns:

the response

Throws:

IOException - if an exception occurs

ConnectException - if an error occurred while attempting to connect to a remote address and port.

SocketTimeoutException - if the received timeout is exceed

onMessageCompleteReceived

protected void onMessageCompleteReceived(IHttpMessageHeader header)

Overrides:

onMessageCompleteReceived in class org.xlightweb.AbstractHttpConnection

isServerSide

public boolean isServerSide()

Specified by:

isServerSide in interface IConnection

setResponseBodyDefaultEncoding

public void setResponseBodyDefaultEncoding(String defaultEncoding)

set the response body default encoding. According to RFC 2616 the initial value is ISO-8859-1

Parameters:

encoding - the defaultEncoding

setResponseTimeoutMillis

public void setResponseTimeoutMillis(long responseTimeoutMillis)

set the response time out by performing the call or send method.

Specified by:

setResponseTimeoutMillis in interface IHttpClientEndpoint

Parameters:

responseTimeoutMillis - the response timeout

getResponseTimeoutMillis

public long getResponseTimeoutMillis()

returns the response timeout

Specified by:

getResponseTimeoutMillis in interface IHttpClientEndpoint

Returns:

the response timeout

send

public BodyDataSink send(IHttpRequestHeader requestHeader,
                         IHttpResponseHandler responseHandler)
                  throws IOException,
                         ConnectException

send the request. If the content-length header is not set, the message will send in chunked mode

• Connection-LifeCycle support: If the request header contains a 'Connection: close' entry, the connection will be closed after the HTTP transaction

Specified by:

send in interface IHttpClientEndpoint

Parameters:

requestHeader - the request header

responseHandler - the response handler or null (supported: IHttpRequestHandler, IHttpSocketTimeoutHandler)

Returns:

the body handle to write

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

send

public BodyDataSink send(IHttpRequestHeader requestHeader,
                         int contentLength,
                         IHttpResponseHandler responseHandler)
                  throws IOException,
                         ConnectException

send the request in a plain body mode

• Connection-LifeCycle support: If the request header contains a 'Connection: close' entry, the connection will be closed after the HTTP transaction

Specified by:

send in interface IHttpClientEndpoint

Parameters:

requestHeader - the request header

contentLength - the content length

responseHandler - the response handler or null (supported: IHttpRequestHandler, IHttpSocketTimeoutHandler)

Returns:

the body handle to write

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

send

public IFutureResponse send(IHttpRequest request)
                     throws IOException,
                            ConnectException

send the request.

• Connection-LifeCycle support: If the request header contains a 'Connection: close' entry, the connection will be closed after the HTTP transaction
• Continue support: If the request header contains a 'Expect: 100-continue' entry, the body will be buffered internal and transmitted after receiving the server's 100-continue response

Specified by:

send in interface IHttpClientEndpoint

Parameters:

request - the request

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

send

public void send(IHttpRequest request,
                 IHttpResponseHandler responseHandler)
          throws IOException,
                 ConnectException

send the request.

• Connection-LifeCycle support: If the request header contains a 'Connection: close' entry, the connection will be closed after the HTTP transaction
• Continue support: If the request header contains a 'Expect: 100-continue' entry, the body will be buffered internal and transmitted after receiving the server's 100-continue response

Specified by:

send in interface IHttpClientEndpoint

Parameters:

request - the request

responseHandler - the response handler or null (supported: IHttpRequestHandler, IHttpSocketTimeoutHandler)

Throws:

ConnectException - if an error occurred while attempting to connect to a remote address and port.

IOException - if an exception occurs

getMessageHeaderHandler

protected org.xlightweb.AbstractHttpConnection.IMessageHeaderHandler getMessageHeaderHandler()

Specified by:

getMessageHeaderHandler in class org.xlightweb.AbstractHttpConnection

removeMessageHandler

protected void removeMessageHandler(org.xlightweb.AbstractHttpConnection.IMessageHeaderHandler messageHandler)

toString

public String toString()

Overrides:

toString in class org.xlightweb.AbstractHttpConnection
